16.07kWh LiFePO4 Battery – EVION POWER (PRO Series)

EVION POWER PRO Series – 16.07kWh LiFePO4 Battery

Power Beyond Limits

The EVION POWER 16.07kWh PRO Series Lithium Iron Phosphate (LiFePO4) Battery is a high-performance energy storage solution developed for residential and small commercial solar systems. Combining advanced lithium battery technology, intelligent monitoring, powerful charging and discharging capabilities, and expandable storage, it provides reliable energy management and dependable backup power.

Key Features

16.07kWh Energy Storage Capacity – High-capacity energy storage for residential and small commercial applications.

Advanced LiFePO4 Technology – Reliable lithium iron phosphate battery technology.

8000+ Charge Cycles – Long-lasting performance at 80% Depth of Discharge (DOD).

Fast Charging & Discharging – Supports a maximum charge/discharge current of 150A.

Smart WiFi Connectivity – Cloud-based monitoring, real-time battery diagnostics and proactive maintenance.

IP65 Protection – Strong environmental adaptability for suitable outdoor installations.

Expandable Energy Storage – Supports up to 16 batteries connected in parallel.

RS485/CAN Communication – Enables integration with compatible solar energy systems.

Optional Self-Heating Technology – Additional support for low-temperature environments.

10-Year Warranty – Long-term product assurance, subject to terms and conditions.

Technical Specifications

Brand: EVION POWER

Series: PRO Series

Model: EVP-X16V1

Battery Type: Lithium Iron Phosphate (LiFePO4 / LFP)

Battery Energy: 16.07kWh

Rated Capacity: 314Ah

Nominal Voltage: 51.2V

Operating Voltage: 48V–57.6V

Charge/Discharge Current: 120A

Charge/Discharge Power: 6,144W

Maximum Charge/Discharge Current: 150A

Maximum Charge/Discharge Power: 7,680W

Maximum Parallel Capacity: Up to 16 Units

Communication: RS485/CAN

Cycle Lifespan: 8000+ Cycles (80% DOD)

Charging Temperature: 0°C to 55°C

Discharging Temperature: -30°C to 55°C

Continuous Operating Temperature: 15°C to 35°C

Mounting Method: Floor-Mounted

Dimensions (L × W × H): 860 × 225 × 820 mm

Weight: 134kg

Warranty: 10 Years (Terms & Conditions Apply)

Country of Manufacture: Sri Lanka

Ideal Applications

Residential solar energy storage

Small commercial solar energy systems

Hybrid solar installations

Home and business backup power solutions

Expandable battery storage systems

Why Choose EVION POWER?

The EVION POWER PRO Series combines advanced LiFePO4 technology, intelligent battery monitoring, efficient power delivery and long-term reliability. Designed to support modern solar energy requirements, it offers a dependable and expandable storage solution for homes and small businesses.

Made in Sri Lanka
